Dometic 8700 Manual Awning 10' Charcoal Black
SKU: 8700Awning Learn More»
CALCULATE SHIPPING:
Accessories List:
Description
Dometic 8700 Manual Roll-Up Awning
Enjoy your outdoor living space with the Dometic 8700 awning. The strong and effective awning will provide protection and shade from the sun. It’s robust, secure and easy to set up, so that you can quickly create an extended living space.
What a Dometic awning does for you
When travelling in your RV you have the privilege of being free to stop at the most beautiful places. Simply turn off the ignition, get the table and chairs out, and enjoy the marvellous view. A Dometic awning gives you added pleasure: It turns the area in front of your vehicle into your personal mobile patio, which will give you many relaxing hours! The awning provides shade as well as protection against rain, wind and weather and it can do so much more. With the right accessories you can quickly create an extra living or sleeping room for your recreational vehicle, complete with windows, doors, curtains, fly screens and lighting.
Premium quality awning you can depend on
Enjoy the great outdoors in shaded comfort wherever you are with the Dometic 8700 awning. The rugged and durable construction coupled with ease of operation makes it a perfect choice for RV enthusiasts. Relax under the shade and be protected from the sun’s harmful rays with the UV protected polyester reinforced vinyl fabric. The quality heavy-duty material and protection properties aides in fading, scratching and mold prevention. The vinyl cushioned lift handle and cam lock system holds the awning secure for total control, which means it can be conveniently set up by a single person with ease. So, you can spend more time relaxing and less on setting up.
Size and Colour Options
- 10' : Charcoal Black (878BK10) or Polar White (878WH10)
- 11' : Charcoal Black (878BK11) or Polar White (878WH11)
- 12' : Charcoal Black (878BK12) or Polar White (878WH12)
- 13' : Charcoal Black (878BK13) or Polar White (878WH13)
- 14' : Charcoal Black (878BK14) or Polar White (878WH14)
- 15' : Charcoal Black (878BK15) or Polar White (878WH15)
- 16' : Charcoal Black (878BK16) or Polar White (878WH16)
- 17' : Charcoal Black (878BK17) or Polar White (878WH17)
- 18' : Charcoal Black (878BK18) or Polar White (878WH18)
- 19' : Charcoal Black (878BK19) or Polar White (878WH19)
Features
- Secure locking system: Cam lock system secures the awning for total control when extending and rolling up
- Quality fabric: Heavy-duty vinyl with UV protection
- Stylish valance: Contemporary straight valance to suit all vehicles
- Ease of use: Ergonomically designed vinyl cushioned lift handles
- Durable materials: Die casted components and solid metal shaft to ensure longevity of awning
- Safety first: Patented Easy Lock Flipper provides additional security and confidence whilst traveling
- Heavy-duty vinyl with UV protection
- Total operator control where one person can easily open or close the awning
- Secure cam system allows for controlled extension and roll up of the awning
- Extruded alloy one-piece heavy-duty roller tube
- Die cast end caps create a polished finish
- Heavy-duty torsion spring assemblies and solid metal shaft
- Full extension length of 2.4 m
Specifications
- Dimensions: 2134 x 102 x 102 mm (W x D x H) | 2500 mm projection
- Net weight: 10.70 kg
- Fabric type: Double-sided Vinyl
- Drive assembly operation type: Manual
- Number of scissor arms: 0
Comparing 8700, 8500 and 8300 Awnings
Note: swipe left or right to see the complete data
| 8700 Awning | 8500 Awning | 8300 Awning | |
| Description | Wall mounted awning | Wall mounted awning | Wall mounted awning |
| Scope of Delivery | Awning in cardboard tube | FRTA | FRTA |
| Depth | 102 mm | 96.52 mm | 100 mm |
| Height | 102 mm | 96.52 mm | 100 mm |
| Width | 2134 mm | 4876.8 mm | 3048 mm |
| Weight | 10.7 kg | 20.95 kg | 10.21 kg |
| Projection | 2500 mm | 2311 mm | 2311 mm |
| Fabric Type | Double-sided Vinyl | Double-sided Vinyl | Double-sided Vinyl |
| Drive Assembly Operation Type | Manual | Manual | Manual |
* Please note that the 8700 hardware (sold separately - see under 'Accessories' and below) is required to install a new awning. However, the 8700 awning can also be installed using hardware purchased for a previous model (8300 / 8500) - it can therefore be retrofitted to the old hardware if required.
8700 Hardware
**Please note that tension rafters are required for awnings 19' and over. Tension rafters are sold separately - see under 'Accessories' and below.
Tension Rafters
- Dometic Tension rafter with centre support - white (930039.500B)
- Dometic Tension rafter with centre support - black (930039.500U)
- Dometic Tension rafter without centre support - white (930042.500B)
- Dometic Tension rafter without centre support - black (930042.500U)
Specifications
SKU 8700Awning
Brand Dometic
GTIN 878BK11
Product Category RV Awnings
Length 10' - 19'
Weight (kg) 10.7
Extension 2500 mm
NOTE: see full product specifications & further product info in the Description section on this page.
Q & A
-
Does the 8700 awning come with the arms to hold it up?
The Dometic 8700 awning does not come with the hardware. You will need to select your colour option of black or white. Then choose standard or tall hardware based on the height of your caravan. You can find these in the accessories list
-
My caravan is 1800 tall, which hardware do I need for my Dometic awning
Standard hardware suits caravan height range of between 1626 mm - 1930 mm Tall hardware suits caravan height range of between 1892 mm - 2235 mm. These measurements are taken from the ground to where your sail track is fitted
-
Does the Dometic Roll out awning come with the sail track?
The Dometic 8700 Awning does not come with the sail track included.
-
Can you replace just the fabric on the Dometic Awning
When replacing the vinyl, Dometic supply it on the tube/roller, so all you have to do is feed it through your sail track and attach to your existing arms
Reviews
Excellent
By: Bec on14 November 2024
awning as described, easy to fit and looks great thank you.
Dometic 8700 Manual Awning
By: Ken Daly on5 August 2024
Easy to install and is of good quality. Exactly as described.
Dometic 8700
By: Stephen Swansbury on12 July 2024
All good , much better quality than previous awning
Excellent
By: anonymous26 February 2024
We purchased the Dometic awning to replace our old one we weren’t real sure on the size we needed but spoke to staff at RV Caravan and they were very helpful so it was very easy to attach to van and awning arms . The quality is great colour black n white overall really happy with it aswel as price great value
Warranty
Warranty Period: 1 Year
Warranty Details: Please CLICK HERE for Warranty Information on this product
