Bluetti AC200MAX Expandable Power Station 2048Wh

SKU: AC200MAX-AU-GY-BL-00 Learn More»
Bluetti AC200MAX Expandable Power Station 2048Wh
Free Shipping
$2,444
$2,699
In Stock1-2 Days Dispatch
EXTRA $40 OFF! Add to cart to get an instant discount
SALE ENDS:

FREE SHIPPING

This item is sent via Express Courier. All freight is fully insured.

Accessories List:

$1,969

$2,574

$1,179

Sold Out

$199

$35

Sold Out

$219

Sold Out

$449

Click '+' to show more accessories

Description

Bluetti AC200MAX Expandable Power Station 2048Wh

BLUETTI first expandable power station-AC200MAX with 2,048Wh LiFePO4 cells and 2,200W pure sine wave inverter. Your mobile power center at home or on the way.



  • 2,200W AC Pure Sine Wave Inverter (4,800W Surge).
  • 2,048Wh Capacity.
  • LiFePO4 Battery with 3,500+ Life Cycles to 80%
  • Expandable Up To 6,144Wh with 2×B230, or 8,192Wh with 2×B300
  • 7 Ways to Recharge (AC/Solar/Car/Generator/Lead Battery/Dual AC/AC+Solar)
  • 900W Max. Solar Input
  • 1300W Max. Fast Dual Charging (Solar + AC Adapter)
  • Smart Control & Monitor in BLUETTI App



Features:

  • Capacity or Flexibility. We've got you covered! AC200MAX supports up to two B230(2,048Wh each) or B300 (3,072Wh each) battery modules for a staggering 8,192Wh! (B230 and B300 battery pack are sold separately)

  • Charge the Way You Prefer. AC200MAX allows 900W solar and 400W adapter input to get a 1,300W total charging rate, charging up this power beast in less than two hours!

  • Stay Connected in Real-time. With smart BLUETTI App, you can monitor, optimize your power consumption and update firmware over-the-air (OTA) from a distance.

  • Incomparable Outlet Versatility. With AC200MAX’s 15 outlets, you get to run all your needs simultaneously without breaking a sweat.

  • Never Run Out of Power. Suitable for various occasions



Specifications:

BATTERY INFO:

  • Capacity: 2048Wh
  • Amp Hours (Ah) @ V: 40Ah @51.2V
  • Cell Chemistry: LiFePO4 (Lithium Iron Phosphate)
  • Lifecycle: 3,500+ Cycles to 80% Original Capacity
  • Shelf-life: Recharge to 80% Every 3-6 Months
  • Management System: MPPT Controller, BMS, etc

OUTPUT:

  • AC Output: 4 x 220V-240V,2200W In Total
  • Inverter Type: Pure Sine Wave
  • Surge Power: 4800W
  • USB-C Port:
    • 2 x 5V/3A USB-A
    • 2 x 18W USB-A
  • 12V DC Outlets:
    • 1 x 12V/30A (RV Outlet)
    • 1 x 12V/10A (Car Outlet)
    • 2 x 12V/10A DC 5521 (5.5mm Outlet)
    • *All Regulated.
  • Wireless Charging Pad: 2 x 15W Max. (For Each)

INPUT:

  • AC Adapter Input: 400W.
  • Solar Input: 900W Max.OCV 10-145VDC, 15A
  • Car Input: 12/24V from Cigarette Lighter Port
  • Max Input: 1,300W, with AC+Solar Input

RECHARGE TIMES:

  • AC Adapter (400W): â‰ˆ5.5~6 Hours
  • Solar (900W): â‰ˆ3~3.5 Hours (With prime sunshine, ideal orientation and low temperature)
  • 12V/24V Car Outlet (100W/200W): â‰ˆ10 or 20 Hours
  • AC Adapter + Solar (1300W): â‰ˆ2.0~2.5 Hours (With prime sunshine, ideal orientation and low temperature)
  • Dual AC Adapters (800W): â‰ˆ3~3.5 Hours (Extra adapter is REQUIRED)

GENERAL:

  • Scalability: Expandable w/ Up to 2 x B230 or 2 x B300
  • Pass-through Charging: Yes
  • Weight: 28.1kg
  • Dimensions (LxWxD): 420 x 280 x 387mm
  • Operating Usage Temperature: -4-104℉ (-20-40℃)
  • Storage Temperature: 14-113℉ (-10-45℃)
  • Certification: UL, CEC, DOE, FCC, CA Prop 65
  • Warranty: 2 Years

Show More

Specifications

SKU AC200MAX-AU-GY-BL-00

Brand Bluetti

GTIN 6970991291883

Product Category Power Packs

Amp Hours (Ah) @ V 40Ah @51.2V

Dimensions 420 x 280 x 387mm

Weight (kg) 28.10

Watt hours (Wh) 2048


NOTE: see full product specifications & further product info in the section on this page.

Q & A


  • What is the largest capacity solar panels that the Bluetti AC200MAX can handle?

    The AC200MAX can now handle up to 900W of solar input, due to the upgraded inbuilt 30amp MPPT controller.

  • Can I use non Bluetti branded solar panels with my Bluetti Lithium Power Station?

    Yes, provided your solar panel/s have MC4 Connectors which will attach to the Bluetti Power Station. If your solar panel has an Anderson connector, you will need to buy an Anderson to MC4 charging cable. Please also note that each power station will have a maximum open circuit voltage.

  • How many BLUETTI B300 or B230 expansion batteries can connect with the AC200MAX?

    Two B300 for 8,192Wh capacity.

    Two B230 for 6,144Wh capacity.

  • Can I connect third-party expansion batteries to AC200MAX?

    No. AC200MAX ONLY accepts BLUETTI B230 or B300 expansion batteries.

  • Does AC200MAX support App control?

    Yes. Once connected via Bluetooth, the BLUETTI App will enable you to control the AC200MAX remotely, like switching the working mode and upgrading the firmware.

  • Can I use AC200MAX as a UPS?

    No.

  • What kind of solar panels should I choose for AC200MAX?

    PV input requirements for AC200MAX:

    1. Open Circuit Voltage: 10-145V

    2. Input Power: 900W Max.

    3. Include MC4 connectors.

    Highly Recommended:

    • 6x BLUETTI PV120: ≈3.5hrs.
    • 4x BLUETTI PV200: ≈3hrs.
    • 2x BLUETTI PV350: ≈3.5hrs.

    * For reference ONLY."

  • Can I connect two units of AC200MAX together for more power?

    No

  • Is the AC200MAX power station waterproof?

    No. Also, please do NOT store it in a humid environment for a long time

  • Can it charge and discharge at the same time?

    Yes

  • Can I use or charge AC200MAX in sub-zero temperatures?

    Temperature ranges for AC200MAX are:

    Charge: 0-40℃ (32-104℉);

    Discharge: -20-40℃ (-4-104℉);

    Storage:-10-45℃ (14-113℉ ).

    Technically, it can power electrical devices under such situations, but please avoid charging it.

  • How do I know whether my appliance can work well with the AC200MAX?

    Calculate the total wattage of your devices. AC200MAX should work if the load doesn't exceed its rated 2,200W.

  • How long can it run my device?

    Running time = Battery capacity x DoD x η ÷ Device rated power DoD refers to Depth of Discharge and η is local inverter efficiency.

    For AC200MAX, both DoD and η are 90%. If you run a 1,000W microwave oven with it, the running time will be: 2,048Wh x 90% x 90% ÷ 1,000W ≈ 1.65hrs

    Note:

    1) The formula is NOT suitable for inductive loads with compressors, like refrigerator, air conditioner, etc.

    2) The above data is for reference ONLY.

  • What is the maximum input charging power of the BLUETTI AC200MAX?

    1,400W Max. Via 500W wall socket and 900W solar panels simultaneously.

  • Can it be laid on its side to save space?

    No. Long-term placement will make the internal structure loose, it is recommended to place the machine upright.

  • Can I hot-swap expansion batteries to AC200MAX?

    Yes. You can easily swap battery packs for continuous power use, and the system can hold two batteries at once.

  • Is it possible to replace the built-in battery?

    No. If the battery pack is faulty or even dead, please contact BLUETTI Customer Service.

  • What is the difference between the AC200MAX and AC200P?

    The main differences are:

    1. Output power and capacity: 2,200W AC power and 2,048Wh capacity for AC200MAX, while 2,000W and 2,000Wh for AC200P.

    2. Max. Input: 1,400W for AC200MAX, while 1,200W for AC200P.

    3. App Control: AC200MAX supports BLUETTI App control.

  • I'd like more tutorial videos on the AC200MAX.

    Sure, please follow BLUETTI Support on YouTube

Reviews

Write a product review

Bluetti Power pack

17 December 2023

Perfect for what I required, works well runs coffee machine and tv when silent power is required

Bluetti AC200MAX

16 December 2023


www.caravanrvcamping.com.au Response
Hi Rob, we love that you love your Bluetti. As for the DC2DC option we will reach out to you via email to discuss further

Great little cube of power. Plenty of 240v and battery size good. All great there. My only concern is getting juice into the battery and a good rate. Yes solar will push the juice in to the battery but I don't want to spend heaps on multiple solar blankets and or more power bricks etc. Would be great if I could connect a DCDC for fast charging if anyone has a solution.

Bluetti Battery

23 October 2023

Love this piece of technology. I just take everything I cook on at home, and put in in my Campervan, and then head off and live exactly like I'm still in my own house. How good is that?

Bluetti AC200Max is a winner!

31 August 2023

Excellent product! Peace of mind having a back up to run the house with.

View All Reviews

Warranty

Warranty Period: 2 Years

Warranty Details: Please CLICK HERE for Warranty Information on this product

Delivery

  • We ship Australia-wide with national road express freight companies such as Star Track, TNT and Toll.
  • Small Items are sent with Australia Post via regular post.
  • Delivery times are generally 3-5 days from day of dispatch for major cities (sometimes quicker). Please allow longer for regional and remote areas.
  • Once your item(s) have been dispatched, we will provide you freight tracking information so you can track your delivery to your door.
  • Items are fully insured during the freight process.
  • Unfortunately we cannot deliver to PO Boxes.
  • For further details on our Delivery Process you can visit our Delivery Page HERE.
