Bluetti AC500 5000W Inverter Module Generator (B300S/B300 Required)

Bluetti B300 Expansion Battery 3072Wh

• Features with a 100W USB-C, a 12V/10A car output and a USB-A ports, you can use the B300 as a portable power station.
• The smart MPPT inside of the B300 enables it to recharge quickly through solar power at a 200W maximum loading scale.
• You can also recharge it by wall socket (Sold separately), car charging or lead-acid battery.
• Car charging and lead-acid battery charging need to be realized through D050S

Features:

• Flexible Recharging. You can recharge BLUETTI B300 quickly with 200W Max. solar input thanks to the built-in MPPT. Besides, it also supports AC (Sold separately), car, and lead-acid battery charging. The car and lead-acid battery charging need a D050S.

• Versatile Power Source. You can power your smartphones, laptops, fans, lights, refrigerators, microwave ovens, and so on with specific output port - the 100W USB-C, 12V/10A cigarette lighter, and 18W USB-A output ports.

• Expandable Battery Pack. B300 has 3,072Wh capacity and over 3,500 life cycles with the LifePO4 battery cells, offering up to 80% of original capacity. Moreover, it will double, triple, even quadruple the total capacity with BLUETTI AC200MAX, AC200P, or AC300 series.

• Home Backup and Trip Power Bank. Whether in a family gathering or camping trip, B300 will serve as your backup power supply or power bank. It powers your home and camping necessities well, and all you need to do is enjoy the good times.

• Never Run Out of Power. Suitable for various occasions

Specifications:

BATTERY INFO:

• Capacity: 3072Wh(51.2V, 60Ah)
• Type: LiFePO4(Lithium Iron Phosphate)
• Life Cycle: 3500+ Cycles to 80% Original Capacity
• Shelf-Life: Recharge to 80% Every 3-6 Months
• Management System: MPPT Controller, BMS, etc.

OUTPUT:

• USB-C Port: 1 x 100W Max.
• USB-A Port: 1 x 18W USB-A
• 12V DC Outlet*:1 x 12V/10A (Car Outlet) *All Regulated.

INPUT:

• AC Input: 500W Max
• Solar Input: 200W Max., VOC 12-60VDC, 10A
• Car Input: 12/24V from Cigarette Lighter Port
• Max Input: 700W, With AC Adatper + Solar Input Simultaneously

RECHARGE TIME:

• AC:≈ 6.5~7 Hours at 500W
• Solar: ≈ 15.5~16 Hours at 200W (With prime sunshine, ideal orientation and low temperature)
• 12V/24V Car Outlet (100W/200W): ≈ 30 or 15 Hours
• AC + Solar: ≈ 5 Hours at 700W (With prime sunshine, ideal orientation and low temperature)
• Solar + Solar: ≈ 5 Hours at 700W (D050S DC Charging Enhancer REQUIRED)
• Dual AC:≈ 5 Hours at 700W (Extra adapter REQUIRED)

GENERAL:

• Pass-through Charge: Yes
• Weight: 79.6lbs(36.1Kg)
• Dimensions (LxWxD): 20.5*12.5*10.5 inch ( 52 x 32 x 26.6cm)
• Operating Usage Temperature: -4-104℉ (-20-40℃)
• Storage Temperature: -4-104℉ (-20-40℃)
• Certification: UL Standard, CEC, DOE, FCC, CA Prop 65
• Warranty: 2 Years

Bluetti B300S Expansion Battery 3072Wh (Only Works With AC500)

Features:

• Flexible Recharging. BLUETTI B300S takes up to 500W AC, solar, or car charging. Combine AC with solar or car input, you can top up B300S in less than 3.5-4 hours with a maximum of 1,000W* input rate. *The D050S DC charging enhancer is required.
• Versatile Power Source. You can power your smartphones, laptops, fans, lights, refrigerators and more with specific outputs-100W USB-C, 12V/10A cigarette lighter, and 18W USB-A.
• Responsive Even in Chilly Winter. Waking up electronics on a freezing day may be time-consuming. But with the Self-heating Function, B300S will automatically heat up to work actively and smoothly as usual.
• Expandable Battery Pack. As the companion battery pack to AC500, B300S has a capacity of 3,072Wh and lasts for 3,500+ cycles to 80% of its original capacity. Hook up 6*B300S with AC500, you'll get a powerhouse with 18,432Wh, enough to get you through a severe power outage.
• Never Run Out of Power. Suitable for various occasions.

Specifications:

BATTERY INFO

• Capacity: 3,072Wh (51.2V, 60Ah)
• Cell Chemistry: LiFePO4 (Lithium Iron Phosphate)
• Life Cycles: 3,500+ Cycles to 80% Original Capacity
• Shelf-life: Recharge to 80% Every 3-6 Months
• Management System: MPPT Charge Controller, BMS, etc.

OUTPUT

• USB-C Port: 1 x 100W Max.
• USB-A Port: 1 x 18W
• DC Outlets: 1 x 12V/10A (Car Outlet) *All regulated.

INPUT

• AC Input: 500W Max.
• Solar Input: 500W Max. VOC 12-60VDC, 10A
• Car Input: 12/24V from Cigarette Lighter Port
• Maximum Input: 1,000W (AC + Solar), with D050S DC Charging Enhancer

GENERAL

• 3,072Wh LiFePO4 battery for over 3,500 life cycles to 80%.
• Standalone power station with 100W USB-C, 12V/10A car port and USB-A port.
• Flexible charging via AC, solar and car power sources.
• Responsive even in freezing days with Self-heating Function.
• Compatible with AC500 for a maximum of 18,432Wh capacity.
• Simultaneous Charge & Discharge: Yes
• Weight: 83.3lbs (38kg)
• Dimensions (LxWxD): 20.5 x 12.5 x 10.5in (52 x 32 x 26.6cm)
• Operating Temperature: -4℉-104℉ (-20℃-40℃)
• Storage Temperature: -4℉-104℉ (-20℃-40℃)
• Certification: UL Standard, CEC, DOE, FCC, CA Prop 65
• Warranty: 4 Years

Included:

• B300S Expansion Battery
• Battery Extension Cable (P150D)
• Solar Charging Cable (MC4 to Aviation Cable)
• Warranty Card
• User Manual
• Certificate Card

Bluetti Car Charging Cable for AC300/AC500/EP500PRO

Used to charge the BLUETTI AC300/AC500/EP500Pro via car cigarette lighter port.

Bluetti M28 Bayonet 3-pin Male Connector for AC500

Often used with generators, temporary power supplies, industrial machinery, and marine power. It is suitable to connect the AC500 system to your home single-phase network and deliver up to 32A rated current and 5000W continuous power.

Bluetti P090D To P150D External Battery Connection Cable for AC500

Applicable Models: AC50 (Only for B300 connected to AC500）

Note: To connect the Bluetti AC500 to a B300 battery the P090D To P150D cable is needed.

Bluetti Folding Trolley

BLUETTI foldable trolley can hold up to 330 lbs, making it easy to transport your power stations, furniture, gardening tools and more. It has 360° universal front wheels and a foot brake system, so you can move and stop it anywhere. Plus, it closes easily into a compact size of 33.3" x 29.4" x 37.7", which is handy for storing in your trunk or garage.

Features:

• 330lbs Total Load Capacity. A heavy-duty frame made of high-quality metal and a durable base plate that easily holds one AC500 and two B300S.
• Maneuverability. The trolley has 360° front wheels and a foot-brake system, allowing you to move and stop it freely.
• Easy Storage. The trolley can be folded or unfolded in seconds and doesn't take up much space - a compact size of 33.3"×29.4"×14.6", so you can easily store it in your trunk or garage.
• Versatile Uses.Not just for carrying BLUETTI power stations, you can also use this trolley to carry your furniture, gardening supplies, luggage and other heavy items.
