EcoFlow 110W Monocrystalline Folding Solar Panel
SKU: EFSOLAR110N Learn More»
FREE SHIPPING
This item is sent via Express Courier. All freight is fully insured.
Accessories List:
Description
EcoFlow 110W Monocrystalline Folding Solar Panel
Stay off the grid with EcoFlow 110W Solar Panel. Made up of efficient monocrystalline silicon cells, it can recharge portable power stations and your electric devices, and keep your equipment running without interruption when connected to our portable power station.
This 110W panel is designed to be connected with compatible EcoFlow Power Stations:
- EcoFlow River600 Portable Power Station (24Ah@12V) - EFRIVER600
- EcoFlow River600 PRO Portable Power Station (60Ah@12V) - EFRIVERPRO
- EcoFlow DELTA Portable Power Station (105Ah@12V) - EFDELTA13
- EcoFlow DELTA MAX 2000 Portable Power Station (168Ah@12V) - EFDELTAMAX
Please note that the open circuit voltage (VOC) for this panel is 21.7V. If you are planning on connecting this solar panel to a standard battery via a regulator, please take the high voltage into consideration.
Features:
- Powerfully portable: With an industry-leading 23% conversion rate, it’s far lighter and approx. 10% smaller than similar portable solar panels on the market. That means a faster, easier charge wherever you are.
- Self-supportable: Take it camping, on a road trip or in your backyard with a case that doubles as a stand. Unzip and prop up your panel at just the right angle to ensure maximum solar coverage.
- Waterproof & Durable: Designed to withstand your adventurous lifestyle, this seamless panel is submersible up to a meter for 30 minutes, and an ETFE film protects against ultraviolet rays.
- It comes with a carry case too: On the go? Keep your panel folded up and protected while you hit the road. Save valuable trunk space and go easy knowing your panel is safe. Once you arrive, simply unfold, prop up and start generating clean, green electricity.
Specifications:
- Dimensions (Open): 51.4 x 158 x 2.4 cm
- Dimensions (Closed): 51.4 x 42 x 2.4 cm
- Weight: 6kg
- Warranty: 12 Months
- Rated Power: 110W(+/-5W)*
- Efficiency: 21%-22%
- Connector Type: MC4
- Open Circuit Voltage: 21.7V(Vmp 18.5V)
- Short Circuit Current: 6.3A(Imp 6.0A)
- Cell Type: Monocrystalline Silicon
- Operating & Storage Temperature: -4° F to 185° F (-20° C to 85° C)
.png)
Specifications
SKU EFSOLAR110N
Brand EcoFlow
GTIN 4897082661023
Product Category Solar Panels
Watts (W) 110
Solar Panel Cell Type Monocrystalline
Solar Panel Type Folding Solar Panels
Dimensions (open) 51.4 x 158 x 2.4 cm
Dimensions (closed) 51.4 x 42 x 2.4 cm
Weight (kg) 6
NOTE: see full product specifications & further product info in the Description section on this page.
Q & A
-
Can I charge my regular deep cycle batteries with the EcoFlow 110W solar blanket?
You can use this solar panel to connect to other regular deep cycle batteries. You will need to ensure you have a solar regulator that can accept VOC (open circuit Volatge) and Max Current of the 160W panel. Voc(V) 21.7V Max Current 6.3A .
This 110W panel is designed to be connected with compatible EcoFlow Power Stations:
- EcoFllow Delta Mini
- EcoFlow DELTA
- EcoFlow River
- EcoFlow River Pro
- EcoFlow River Max
These power stations all have a built in solar regulator, so the connection is plug and play.
-
What should I do if my solar panel isn't charging my portable power station?
- Please note that portable solar panels must be placed outdoors. They cannot charge a power station if placed indoors without exposure to sunlight.
- Check whether there is a connection issue and then try again.
- Confirm whether the input voltage and amperage match the specification of the portable power station. Also, check whether the positive and negative terminals are connected in reverse.
- Check the display for error prompts and resolve the issue accordingly.
- Third-party cables longer than 3 meters should have a wiring harness with a diameter of 6.5 mm and a wire diameter of 4 mm2, otherwise there will be no input power on the display screen.
- If the portable solar panel still does not work properly after trying the above steps, connect the portable power station to a car outlet using the XT60 port. Contact after-sales for help and send a video of the steps you have carried out.
-
What are the solar panels made from? What is their waterproof rating?
They're made from monocrystalline silicon which is more efficient than polycrystalline. New materials like EVA and ETFE protect against high temperatures, corrosion, sunlight, as well as damage, which ensures that they can be used outdoors for long periods. They have a waterproof rating of IP67 and are also resistant to dust and UV rays.
-
What is the Portable Solar Panels Output Power
- The portable solar panel's output power is about 80% of the rated power in strong, vertical sunlight. For example, a 110W portable solar panel has an output power of around 90W.
- In partially cloudy weather, approximately 20-30W.
- 5-10W in cloudy weather.
- Raining/evening: 0W
When the current input power of the portable solar panel is very low, charging with solar power is not recommended. The standby power consumption may be higher than the input power, causing the battery voltage to leak and damage the battery.
-
Is it compatible with any portable power station?
It's compatible with all EcoFlow portable power stations, and any other portable power station that can connect with solar cables.
