Enerdrive 190W Mono Crystalline Fixed Solar Panel, Black
SKU: SP-EN190W-B Learn More»
FREE SHIPPING
This item is sent via Express Courier. All freight is fully insured.
Accessories List:
Description
Enerdrive 190W Mono Crystalline Fixed Solar Panel, Black
Enerdrive solar panels are typically around 20+vdc open circuit and are well suited to 12v installations (or 24v by series connections of panels). A fly lead cable is provided for easy connection of the 10 & 20w panels while the larger panels have MC4 compatible solar cable connectors included.
A fly lead cable is provided for easy connection of the 10 & 20w panels while the larger panels have MC4 compatible solar cable connectors included.
Features:
- High Conversion Efficiency. Module efficiency up to 17.86% achieved through advanced cell technology and manufacturing capabilities
- Positive Tolerance. Positive tolerance of up to 0~+5W delivers higher output reliability
- High PID Resistant. Advanced cell technology and qualified materials lead to high PID resistant
- Current Sorting Process. System output maximised by reducing mismatch losses up to 2% with modules sorted and packaged by amperage
- Extended Wind and Snow. Load tests Module certified to withstand extreme wind (2400 Pascal) and snow loads (5400 Pascal)
- Withstanding Harsh Environment. Reliable quality leads to a better sustainability even in harsh environments in the outdoors
Some Basic Tips:
- Keep your panel in direct sunlight as much as possible
- Secure your Folding Solar Kit from theft around your work or campsite
- Protect and store your portable folding kit in the most secure place you can to prevent accidental breakage
.png)
Specifications
SKU SP-EN190W-B
Brand Enerdrive
GTIN 9342616020890
Product Category Solar Panels
Watts (W) 190
Solar Panel Cell Type Monocrystalline
Solar Panel Type Fixed Solar Panels
Operating Voltage 20V
Operating Current (Imp) 9.5A
Open Circuit Voltage Voc(V) 24.8V
Short Circuit Current Isc(A) 10.07A
Module Efficiency 17.86%
Operating Temperature -40℃to +85℃
Maximum Voltage 1000V DC (IEC)
Power Tolerance 0~+5W
STC lrradiance 1000 W/m , module temperature 25 C, AM=1.5; Best in Class AAA solar simulator (IEC 60904-9) used
Number of Cells 36 (4x9)
Front Glass 3.2mm Tempered Glass
Frame Material Anodized Aluminium Alloy
Junction Box IP67 Rated
Output Cables TÜV (2Pfg1169:2007), 4.0 mm (0.006 inches ), symmetrical lengths 900mm and (+) 900 mm
Connector MC4 Connectors
NOCT 45±2 C
Temperature Coefficient -0.37%/ C (of Pmax), -0.30%/ C (of Voc), 0.060%/ C (Isc)
Weight (kg) 11.5
Dimensions 1500 x 680 x 35 mm
NOTE: see full product specifications & further product info in the Description section on this page.
Q & A
-
Is this a good size for my caravan?
Generally speaking yes. The 190w size is our most popular panel, at this size most vans will fit a couple on the roof.
-
What is the frame of the solar panel made of?
Anodized aluminium alloy
-
What are the lengths of the cables coming off the junction box?
These cables are 900mm long.
-
How many of these panels can I run in parallel through my Enerdrive 40a DC2DC?
You can run up to 4x of these panels in parallel.
-
Does this panel have any connectors on the cables?
Yes, it will have MC4 connectors.
-
What is the recommended solar controller fo these panels?
