Exotronic 2 x 225W Fixed Monocrystalline Solar Panel

SKU: 2xExo-SP-F4-225 Learn More»
$579
$798
In Stock1-2 Days Dispatch

EXTRA $20 OFF! Add to cart to get an instant discount
SALE ENDS:

CALCULATE SHIPPING:

Accessories List:

$50

$10

$15

Click '+' to show more accessories

Description

Exotronic 2 x 225W Fixed Monocrystalline Solar Panel



Pack Includes:

  • 2 x Exotronic 225W Fixed Monocrystalline Solar Panel



Using 23% efficient M6 monocrystalline passivated emitter rear contact (mono-PERC) square cut cells and the latest 9-wire bus-bar low-loss design, these panels achieve a high efficiency with a positive power tolerance.

PERC cells provide better performance in low light applications compared to traditional monocrystalline silicone designs as some of the light that passes through the cell is bounced back and converted into electricity.

The 9-wire busbar decreases the resistance of the module and carries current evenly over the whole surface of the cells to ensure that all there are minimal power losses within the module and significantly reduces uneven cell heating and hot spots.

The Exotronic range of panels has been designed so that all panels have closely matching votlages, therefore all sizes can be wired in parallel.

The anodised aluminium frame is further protected by a black protective coating and is only 25mm thick to assist a low-profile design and reduce the weight of the module while still giving good rigidity to protect the module from vibrational and torsional stresses.  The tempered glass provides high resistance to impact damage.  Low-iron high transmissivity glass is used to provide excellent low light performance.

  • Salt mist  and ammonia resistant
  • Wind load resistant - 2400 Pascal
  • Snow load resistant - 5400 Pascal



Specifications:

  • Power: 225W
  • Vmp (V): 20.52
  • Imp (A): 10.96
  • Voc (V): 24.15
  • Isc(A): 12.18
  • Module Efficiency (%): 20.5
  • No. of Cells: 72 ((2x18) x 2)
  • Dimensions: 1570mm x 700mm x 25mm
  • Weight: 11.2kg



Temperature Ratings:

  • NMOT : 47C +/-2C
  • Temperature Coefficient of Pmax: -0.5%/C
  • Temperature Coefficient of Voc: -0.4%/C
  • Temperature Coefficient of Voc: 0.065%/C


Maximum Ratings:

  • Operating Temperature: -40 - +85C
  • Maximum System Voltage: 1000VDC
  • Maximum Fuse Rated Current: 15A


Mechanical Characteristics:

  • Front: 3.2mm Tempered Glass
  • Frame: Black Anodized Aluminium Alloy
  • Junction Box: IP65/IP67
  • Connectors: MC4 Compatible





Show More

Specifications

SKU 2xExo-SP-F4-225

Brand Exotronic

Product Category Solar Bundles

Watts (W) 450

Solar Panel Cell Type Monocrystalline

Solar Panel Type Fixed Solar Panels

-Weight 22.4 Kg

Dimensions 1570mm x 700mm x 25mm
