Morningstar EcoPulse 20 AMP Solar Charge Controller
SKU: SR-EC2 Learn More»
Description
Morningstar EcoPulse 20 AMP Solar Charge Controller
The EcoPulse is a pulse width modulation (PWM) solar charge controller within Morningstar’s Essential Series™ of products which provides essential off-grid battery regulation functions. This controller is easy to use, and designed for residential and leisure consumer applications.* Metered and non-metered versions of this product are available at 10, 20, and 30 amp charge ratings for 12 and 24 volt battery systems.
Specifications:
|
|---|
Features:
- High Reliability – conformally coated circuit board and corrosion resistant terminals
- Robust Thermal Design – extruded aluminum heatsink dissipates heat quickly without using cooling fans
- Durable Casing – high strength polycarbonate case
- LED Fault Indications – alert when short circuit, over current, high voltage, and other error conditions take place
- Automatic Solar Based Lighting Control – field adjustable dusk ‘til dawn setting
- Adjustable Charge Settings – seven presets and a custom setting can be set via DIP Switches or by the meter display buttons
- Adjustable Load Control – load control can be adjusted via meter display
- Optional Meter – multi-lingual interface with scroll buttons to adjust the settings and display metrics
Specifications
SKU SR-EC2
Brand Morningstar
GTIN 9342616026496
Product Category Solar Charge Controllers
Voltage 12/24V
Operating temperature range -40°C -+45°C
Dimensions 105x153x55mm (LxWxD)
Weight (kg) 0.4
Charge Current (A) 20
NOTE: see full product specifications & further product info in the Description section on this page.
Reviews
Be The First To Review This Product!
Help other CARAVANRVCAMPING users shop smarter by writing reviews for products you have purchased.
Warranty
Warranty Period: 5 Years
