Victron Orion IP67 24/12V 10A DC to DC Converter Non Isolated
SKU: ORI241210260 Learn More»
Description
Victron Orion IP67 24/12V 10A DC to DC Converter Non Isolated
Completely encapsulated waterproof, shockproof and ignition protected. Water, oil or dirt will not damage the Orion IP67 DC-DC Converter. The casing is made of cast aluminium and the electronics are moulded in resin.
Specifications:
| Amps | 10.0 Amps |
|---|---|
| DC Input Voltage | 15-40VDC |
| DC Output Voltage | 12V +/- 3% |
| Rating (A) | 10A |
| Operating Temperature Range | -20 to +70°C (full rated output up to 40°C) |
| Overload protection | Hiccup mode, recovers automatically after fault condition is removed |
| Short circuit protection | Yes |
| Protection category | IP67 |
| Efficiency | 93% |
| Dimensions (LxWxH) mm | 32 x 74 x 74 |
| Net Weight (kg) | 0.3 Kg |
| Manufacturers Warranty | 5 Year Warranty |
Features:
Completely encapsulated
Waterproof, shockproof and ignition protected Water, oil or dirt will not damage the Orion IP67 DC-DC Converter. The casing is made of cast aluminium and the electronics are moulded in resin.
Extra-long input and output cables
Thanks to the cables of 1.8 meters in length, intermediate cable interconnections to increase length even more will in most cases not be needed. This is an important reliability increasing feature in an area were IP67 protection grade is needed.
Wide input voltage range
With 15 to 40 Volts input range, a stable output is ensured during surges or sags due to other equipment connected to same battery.
Protected against overheating
It can be used in a hot environment such as a machine room
.png)
Please Note: The image used is not the correct image for this model.
Specifications
SKU ORI241210260
Brand Victron
GTIN 8719076048435
Product Category Converters
Current (A) 10
Dimensions (D x H x W) 32 x 74 x 74 mm
Weight (kg) 0.3
DC Output Voltage 12V
DC Input Voltage 15-40V
Efficiency 0.93
NOTE: see full product specifications & further product info in the Description section on this page.
