Projecta VSR100 100A Voltage Sensitive Relay

SKU: VSR100 Learn More»
$125
In Stock1-2 Days Dispatch

CALCULATE SHIPPING:

Description

Projecta VSR100 100A Voltage Sensitive Relay

The perfect ‘no-fuss’ power management controllers suitable for a wide variety of 12V DC applications, eg. winching etc.

Specifications:

Voltage 12 V
Charger Type Parallel
Charging Control MCU
Fuse Recommended 150A
Cut-in Voltage 13.4V
Cut-out Delay 8 seconds
Charge current 100A Continuous, 200A Peak
Cut-out Voltage 12.8V
Operating Voltage Minimum 10V
Current Draw Charging 550mA (standby 10mA)
Ingress Protection IP66
Cable Length 14mm2 (6 B&S)
Mounting Hole Surface/firewall
Type Approval EMC
Manufacturers Warranty 1 Year Warranty



Features:

  • L.E.D indicator illuminates when VSR is activated
  • Sealed electronics prevents dust and water ingress (IP66)
  • Built-in protection guards vehicle against voltage spikes
  • Bypasses automatic settings allowing relay to engage below set voltages
  • Silver tip contacts provide exceptional current transfer
