Renogy 3000W 12V Pure Sine Wave Inverter Charger with LCD
SKU: R-INVT-PCL1-30123S Learn More»
Description
Renogy 3000W 12V Pure Sine Wave Inverter Charger with LCD
The Renogy 3000W Pure Sine Wave Inverter Charger can be used for multiple applications when going off-grid. A power inverter is an electrical device that transforms the DC power stored in a battery bank into standard household AC power for a user's electronic needs. This device can also charge and maintain a battery bank when connected to shore power and now compatible with Lithium batteries. With a low transfer time, power remains uninterrupted when switching from solar to shore power. This creates clean and silent energy without having to worry about losing access to connected devices and appliances. The Renogy 3000W Pure Sine Wave Inverter Charger is a perfect back-up power source!
Features:
- Robust and sleek design
- LCD and LED display used to view inverter status and programming features
- Offers high quality waveform with little harmonic distortion
- 4-Stage battery charger with configurable charging current
- 8 Pre-Set battery voltages including Lithium; User-defined option available
- Automatic generator start option
- Peak efficiency >90%
- ETL listed with multiple electronic protections
Specifications:
- Rated output power: 3000W
- Surge Power (1 second): 9000W
- Nominal Output Voltage RMS: 230VAC (200~240VAC, 10V interval)
- Output Frequency (Nominal): 50/60 Hz
- Input Voltage Range: 10~16 VDC
- Output Wave form: Pure Sine Wave
- Nominal Efficiency: > 90% Peak
- No Load Power Consumption: Normal: <30W; Power Saving: <15W
- Battery Types: GEL, AGM, SLA, FLD, CAL, LI, USER
- Operating Temperature: 0 ~ 40°C / 32 ~ 104°F
- Output Current: 5-75A; configurable, 5A intervals
- Optimal Efficiency: >85%
- Nominal Input Voltage: 230 VAC
- Input Voltage Range: 155-275 VAC
- Input Frenquency Range: 40Hz - 70Hz
- Input Wave Form: Sine Wave (Utility or Generator)
- Transfer Time: ~ 10ms
- Transfer Rating: 30A
- Dimensions: 510 x 285 x 193 mm
- Weight: 28.8Kg
Specifications
SKU R-INVT-PCL1-30123S
Brand Renogy
GTIN 00810009711834
Product Category Power Inverter Chargers
Voltage 12V
Wattage (W) 3000
Operating temperature range 0 - 40°C
Output Frequency (Nominal) 50/60 Hz
Surge Power 9000W
Battery Types GEL, AGM, SLA, FLD, CAL, LI, USER
Transfer Rating 30A
Nominal Input Voltage 230 VAC
Nominal Efficiency > 90% Peak
Input Voltage Range 10~16 VDC
Input Voltage Range 155-275 VAC
Output Current 5-75A; configurable, 5A intervals
Transfer Time ~ 10ms
Optimal Efficiency >85%
Nominal Output Voltage 230VAC (200~240VAC, 10V interval)
Output wave form Pure Sine Wave
Rated Output Power 3000W
Weight (kg) 28.8
Dimensions 510 x 285 x 193 mm
Input Frenquency Range 40Hz - 70Hz
No Load Power Consumption Normal: <30W; Power Saving: <15W
NOTE: see full product specifications & further product info in the Description section on this page.
Q & A
-
What's the difference between an inverter charger and an inverter?
An Inverter Charger not only converts DC battery power to AC power but also functions as a battery charger when connected to shore power (240v) .
-
Can I operate the inverter with a 24V system?
No, this inverter is designed for a 12V battery system only.
-
Can I utilize this 12V inverter to charge my batteries?
No, inverter is meant solely for converting DC power to AC power. To charge your battery, you would need to consider a Inverter Charger.
-
What size inverter should I purchase?
1. Check your appliances: Identify the wattage rating of each appliance you plan to power. For example, a standard kettle might be 1500W.
2. Calculate total wattage: If you intend to run multiple 240V appliances simultaneously, add their wattage ratings together. For instance, if you plan to run a kettle (1500W) and a microwave (900W), your total would be 2400W. Therefore, you'd need a minimum 2400W inverter.
3. Consider usage: If you can stagger the use of appliances to avoid running them all at once, it can reduce the load on the inverter.
4. Match battery voltage: Ensure the inverter matches the voltage of your battery system. If you have a 12V battery system, choose a 12V inverter. If it's a 24V system, opt for a 24V inverter.
5. Check dimensions: Verify that the physical size of the inverter fits your installation space. Some inverters can be quite large, so measure your available space accordingly.
By following these steps, you can determine the appropriate size of inverter to meet your power needs while considering practical factors like battery voltage compatibility and physical installation space.
-
How do I connect a 12V to 240V inverter? What cable size is recommended, and is it included?
When connecting the power inverter to the battery, Renogy recommend to use the thickest wire available in the shortest practical length. The package includes 20mm²*6m cables with battery terminals.
-
I want something that can charge my battery, can this inverter do this?
No, this inverter is designed solely for 12V to 230/240V conversion. Consider an Inverter Charger for battery charging purposes.
-
Will this 12V to 240V inverter work with lithium batteries?
Yes, as long as the lithium battery is rated for 12V applications.
-
Can I use the Bluetooth Module to monitor the Inverter from my phone? Which Bluetooth Module would you recommend?
Unfortunately, there is no Bluetooth Module compatible with this inverter. We apologize for any inconvenience.
