Victron BlueSolar PWM-LCD&USB 48V-20A Charge Controller
SKU: SCC040020050 Learn More»![](/assets/thumbL/SCC040020050.png?20220105182130)
![](/assets/alt_1/SCC040020050.png?20220105182134)
![](/assets/alt_2/SCC040020050.png?20220105182136)
![](/assets/alt_3/SCC040020050.png?20220105182142)
Description
Victron BlueSolar PWM-LCD&USB 48V-20A Charge Controller
Liquid crystal display:
For status monitoring and set-up
Load output:
Over-discharge of the battery can be prevented by connecting all loads to the load output. The load output will disconnect the load when the battery has been discharged to a pre-set voltage. Some loads (especially inverters) can best be connected directly to the battery, and the inverter remote control connected to the load output. A special interface cable may be needed, please see the manual. The connect and disconnect voltages are adjustable.
Day/night timing of the load output:
This option allows for a pre-set ON-time after dusk.
Programmable battery charge algorithm:
Preprogrammed algorithms for AGM, GEL, Flooded or LiFePO4 batteries (with internal BMS only)
Two 5 Volt USB outputs:
Maximum current (both outputs combined): 2A
Please Note: The image shown is not the correct image for this model.
Specifications:
- Battery Voltage: 48V
- Rated Charge Current: 20A
- Automatic Load Disconnect: Yes
- Maximum Solar Voltage: 100V
- Self-Consumption: < 10 mA
- Load Output: Manual control + low voltage disconnect +timer
- Protections: Battery reverse polarity (fuse) Output short circuit Over temperature
- Operating Temperature Range: -35 to +60°C (full load)
- Humidity (Non-Condensing): Max 95%
- Charge Voltage 'absoprtion': 57.6V
- Charge Voltage 'float': 54.8V
- Low Voltage Load Disconnect: 44.8V
- Low Voltage Reconnect: 50.4V
- Voltage: 5V
- Current: 2A (total from 2 outputs)
- Protection Class: IP20
- Terminal Size: 16mm² / AW
- Weight: 0.3kg
- Dimensions: 101mm x 184mm x 47mm
Specifications
SKU SCC040020050
Brand Victron
GTIN 8719076046240
Product Category Solar Charge Controllers
Charge Current (A) 20
NOTE: see full product specifications & further product info in the Description section on this page.
