Victron BlueSolar PWM-Light Charge Controller 48V-30A

Description

Victron BlueSolar PWM-Light Charge Controller 48V-30A

BlueSolar PWM-Light

• Load output with low battery voltage disconnect function.
• Lighting control function, one timer only.
• Two-digit seven segment display for quick and easy setting of the load output functionality, including timer setting.
• Three-stage battery charging (bulk, absorption, float), not programmable.
• Load output protected against overload and short circuit.
• Protected against reverse polarity connection of the solar array and/or battery.
• Day/night timing options: see the manual for details

Features

• Load output with low battery voltage disconnect function.
• Lighting control function, one timer only.
• Two-digit seven segment display for quick and easy setting of the load output functionality, including timer setting.
• Three-stage battery charging (bulk, absorption, float), not programmable.
• Load output protected against overload and short circuit.
• Protected against reverse polarity connection of the solar array and/or battery.

Specifications:

• Battery Voltage - 48V
• Rated charge current - 30A
• Automatic load disconnect - Yes
• Maximum solar voltage - 100 V
• Self-consumption - < 10 mA
• Load output - Manual control + low voltage disconnect
• Protection - Battery reverse polarity (fuse) Output short circuit Over temperature
• Overload protection  - Shut down after 60 s in case of 130% load |Shut down after 5 s in case of |160% load Short circuit: immediate shutdown.
• Grounding -Common positive
• Operating temp. range -20 to +50°C (full load)
• Humidity (non-condensing) - Max 95%
• Charge voltage 'absorption' - 56.8V
• Charge voltage 'float' - 55.2V
• Low voltage load disconnect - 44.8V
• Low voltage load reconnect - 50.4V (manual) 52.4V (automatic)
• Protection class - IP20
• Terminal size - 6 mm² / AWG10
• Weight - 0.17kg
• Dimensions (h x w x d) - 95 x 140 x 33.5 mm
