Victron BlueSolar PWM-Pro Charge Controller 12/24V-20A
SKU: SCC010020110 Learn More»
CALCULATE SHIPPING:
Accessories List:
Description
Victron BlueSolar PWM-Pro Charge Controller 12/24V-20A
Specifications:
| Amps | 20.0 Amps |
|---|---|
| Voltage | 12 / 24V with automatic system voltage detection |
| Operating Temperature Range | -20 to +50°C (full load) |
| Humidity | Max 98% |
| Dimensions (LxWxH) mm | 48 x 82 x 160 (D x W x H) |
| Net Weight (kg) | 0.3 Kg |
| Charge voltage 'absorption' | 14.4V / 28.8V |
| Protection | Battery reverse polarity (fuse), Output short circuit, and Over temperature |
| Manufacturers Warranty | 2 Years |
Features:
- Lighting control function, fully programmable.
- Three stage battery charging (bulk, absorption, float), fully programmable.
- Integrated battery monitor function (Remote Panel needed to display state of charge).
- Load output with low voltage disconnect and manual control (default setting).
- Optional external temperature sensor. - Load output protected against over load and short circuit.
- Protected against reverse polarity connection of the solar array and/or battery.
The BlueSolar PWM-Pro series is ready for use with its default settings. It also is fully programmable:
• Lighting control function, fully programmable.
• Three stage battery charging (bulk, absorption, float), fully programmable.
• Integrated battery monitor function (Remote Panel needed to display state of charge).
• Load output with low voltage disconnect and manual control (default setting).
• Optional external temperature sensor.
• Load output protected against over load and short circuit.
• Protected against reverse polarity connection of the solar panels and/or battery.
• Day/night timing options: see manual Remote Panel for details.
BlueSolar PWM-Light:
• Load output with low battery voltage disconnect function.
• Lighting control function, one timer only.
• Two digit seven segment display for quick and easy setting of the load output functionality, including timer setting.
• Three stage battery charging (bulk, absorption, float), not programmable.
• Load output protected against over load and short circuit.
• Protected against reverse polarity connection of the solar array and/or battery.
• Day/night timing options: see manual for details
Specifications
SKU SCC010020110
Brand Victron
GTIN 8719076025382
Product Category Solar Charge Controllers
Amps 20A
Operating temperature range Äì20¬∞C to +50¬∞C (full load)
Dimensions 48 x 82 x 160 mm (D x W x H)
Weight (kg) 0.3
Charge Current (A) 20
Voltage (V) 12/24 V with automatic system voltage detection
Protection Battery reverse polarity (fuse), Output short circuit, and Over temperature
NOTE: see full product specifications & further product info in the Description section on this page.
