Victron MultiPlus Compact Inverter/Charger 24/1200/25-16
SKU: CMP241220000 Learn More»
Description
Victron MultiPlus Compact Inverter/Charger 24/1200/25-16
Specifications:
| Peak Power | 2400W |
|---|---|
| Output Voltage and Frequency | 230 Vac ± 2% / 50 Hz ± 0.1% |
| Output Power | 1200W (continuous output power at 25°C) | 900W (continuous output power at 40°C) | 600W (continuous output power at 65°C) |
| Input Voltage | 19 - 33V |
| Charge voltage 'absorption' | 28.8 V |
| Charge Voltage Float - Wet (25 degrees)** | 27.6 |
| Charge voltage 'storage' | 26.4V |
| Inverter Output Nominal Efficiency | 93% (maximum) |
| Product Dimensions (mm) LxWxH | 375 x 214 x 110 |
| Net Weight (kg) | 10 Kg |
Features:
Unique PowerAssist feature
The MultiPlus will prevent overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shore side supply with power taken from the battery.
Uninterrupted AC power (UPS function)
In the event of a grid failure, or when shore or generator power is disconnected, the inverter within the Multi is automatically activated and takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption.
Virtually unlimited power thanks to parallel operation
Up to 6 Multis can operate in parallel to achieve higher power output. Three phase or split phase operation is also possible. Please check the datasheets to see which models have paralleling, three phase and split phase capabilities.
Please Note: The image used is not the correct image for this model.
Specifications
SKU CMP241220000
Brand Victron
GTIN 8719076022022
Product Category Power Inverter Chargers
Voltage 12V
Wattage (W) 1000
Input Voltage 19-33V
Dimensions 110 x 214 x 375mm
Peak Power (W) 2400
Weight (kg) 10
NOTE: see full product specifications & further product info in the Description section on this page.
Q & A
-
Can these chargers take solar input?
No, the battery charging component is an AC input, meaning only AC power (mains power) can charge through this unit.
-
What size Generator can I use with the Multiplus Inverter Chargers?
The below generators are the minimum recommend sizes based on an AVR generator:
Inverter Charger Size Minimum Recommended Generator Size 240V AC Input Current Limit 800VA 2 kVa 5A 1200VA 2.5 kVa 7A 1600VA 3 kVa 10A 3000VA 5 kVa 16A 5000VA 8 kVa 25A If your generator is smaller than the recommended size for your inverter/charger, you will definitely need to adjust the settings on the inverter/charger and reduce the AC input current limit, and/or a DC charge current limit to prevent overloading the generator. If you do want an inverter based generator get one that is at least 30% larger than required than an equivalent AVR based model to help prevent overloads.
Reviews
Be The First To Review This Product!
Help other CARAVANRVCAMPING users shop smarter by writing reviews for products you have purchased.
Warranty
Warranty Period: 5 Years
Warranty Details: Please CLICK HERE for Warranty Information on this product
