Victron MultiPlus-II Inverter Charger 24/3000/70-32 230V
SKU: PMP242305010 Learn More»
FREE SHIPPING
This item is sent via Express Courier. All freight is fully insured.
Accessories List:
Description
Victron MultiPlus-II Inverter Charger 24/3000/70-32 230V
Our new inverter/charger:
The MultiPlus-II combines the functions of the MultiPlus and the MultiGrid. It has all the features of the MultiPlus, plus an external current transformer option to implement PowerControl and PowerAssist and to optimize self-consumption with external current sensing (max. 32A). It also has all the features of the MultiGrid with built-in anti-islanding and an increasingly long list of country approvals.
PowerAssist:
The MultiPlus-II will prevent overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shore side supply with power taken from the battery.
ESS: Energy Storage Systems:
The MultiPlus-II is the key component in a Victron ESS system, providing the flexibility to combine with MPPT Solar Chargers or Grid-tie PV Inverters. For examples and more detailed information see the ESS (Energy Storage System) manual.
Uninterrupted AC power (UPS function):
In the event of a grid failure, or when shore or generator power is disconnected, the inverter within the Multi is automatically activated and takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption.
Remote Monitoring and Control:
Monitor and control your Multi and system or systems' locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop, or PC for multiple operating systems. There is no end to the level of control, via the required Color Control GX or Venus GX, from adjusting your Multi to auto-starting a back generator and more...
Specifications:
| Power Control & Power Assist | Yes |
| Maximum AC input current | 32A |
| DC Input voltage range | 19 – 33V |
| Output |
Output voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0,1% |
| Cont. output power at 25°C | 2400W |
| Cont. output power at 40°C | 2200W |
| Cont. output power at 65°C | 1700W |
| Maximum apparent feed-in power | 2500VA |
| Peak power | 5500W |
| Maximum efficiency | 94% |
| Zero load power | 13W |
| Zero load power in AES mode | 9W |
| Zero load power in Search mode | 3W |
| AC Input |
Input voltage range: 187-265 VAC Input frequency: 45 – 65 Hz |
| Charge voltage 'absorption' | 28.8V |
| Charge voltage 'float' | 27.6V |
| Storage mode | 26.4V |
| Maximum battery charge current (4) | 70A |
| Battery temperature sensor | Yes |
| Auxiliary output | Yes (32A) |
| External AC current sensor (optional) | 50A |
| Programmable relay | Yes |
| VE.Bus communication port | For parallel and three-phase operation, remote monitoring and system integration |
| Remote on-off | Yes |
| Operating temperature range | -40 to +65°C (fan assisted cooling) |
| Humidity (non-condensing) | max 95% |
| Material & Colour | Steel, blue RAL 5012 |
| Protection category | IP22 |
| Battery-connection | M8 bolts |
| 230 V AC-connection | Screw terminals 13 mm² (6 AWG) |
| Weight | 18 kg |
| Dimensions (dxwxh) | 147 x 275 x 506 |
Please Note: The image shown is not the correct image for this model.
.png)
Specifications
SKU PMP242305010
Brand Victron
GTIN 8719076048084
Product Category Power Inverter Chargers
Voltage 24V
Wattage (W) 2400
Input Voltage 19 - 33V
Dimensions 147 x 275 x 506mm
Peak Power (W) 5500
Weight (kg) 18
NOTE: see full product specifications & further product info in the Description section on this page.
Q & A
-
Can these chargers take solar input?
No, the battery charging component is an AC input, meaning only AC power (mains power) can charge through this unit.
-
What size Generator can I use with the Multiplus Inverter Chargers?
The below generators are the minimum recommend sizes based on an AVR generator:
Inverter Charger Size Minimum Recommended Generator Size 240V AC Input Current Limit 800VA 2 kVa 5A 1200VA 2.5 kVa 7A 1600VA 3 kVa 10A 3000VA 5 kVa 16A 5000VA 8 kVa 25A If your generator is smaller than the recommended size for your inverter/charger, you will definitely need to adjust the settings on the inverter/charger and reduce the AC input current limit, and/or a DC charge current limit to prevent overloading the generator. If you do want an inverter based generator get one that is at least 30% larger than required than an equivalent AVR based model to help prevent overloads.
Reviews
Be The First To Review This Product!
Help other CARAVANRVCAMPING users shop smarter by writing reviews for products you have purchased.
Warranty
Warranty Period: 5 Years
Warranty Details: Please CLICK HERE for Warranty Information on this product
